Advanced Instruments PSR-12-333 PPM Oxygen Sensor
This sensor is specifically designed for Advanced Instruments, Inc., trace oxygen analyzer, explosion proof, intrinsically safe transmitters, and portable analyzers.
GPR-1600
GPR-1200
GPR-1100
GPR-18
GPR-1800 Series
GPR-1500 Series
This innovative sensor design carries over many of the features of the traditional galvanic oxygen sensor but poses much higher sensitivity, stability and high signal to noise ratio with 24 months operating life thus offering effective analyzer solution for measuring low levels PPM oxygen analysis.
$218.00
| Measuring Range | 0-10 PPM Oxygen |
| Accuracy 1 | +/-2% of Full Scale |
| Signal Output 2 | 295 – 625 uA |
| Linearity | +/-2% of Full Scale |
| Response T90 | 7 sec |
| Temp Coefficient | compensated |
| Operating Temp | 0 to 45oC |
| Recommended Storage 3 | 0 to 25°C |
| Temperature Coefficient | Compensated |
| Shelf Life 4 | 6 months |
| Humidity Non-condensing | 0-99% RH |
| Expected Life | 18-24 months |
| Warranty 5 | 12 months |
| Electrical Connector | 2 Ring Gold Disk |
