Advanced Instruments XLT-12-123 PPM Oxygen Sensor
LT-12-123, replaces A2C, OX2 & T2, This PPM oxygen sensor is galvanic type oxygen sensor with excellent stability and accuracy under stringent applications. All sensors are subjected to the most extensive stability test, output in air, 30″ of water column pressure test and stability at 100% oxygen.
***Recommended in gas mixtures with CO2 > 0.5%
$140.00
| Measuring Range | 0-25% |
| Accuracy 1 | +/-2% of Full Scale |
| Signal Output 2 | 295 – 625 uA |
| Linearity | +/-2% of Full Scale |
| Response T90 | 7 sec |
| Temp Coefficient | un-compensated |
| Operating Temp | 0 to 45°C |
| Recommended Storage 3 | 0 to 25°C |
| Temperature Coefficient | Compensated |
| Shelf Life 4 | 6 months |
| Humidity Non-condensing | 0-99% RH |
| Expected Life | 18-24 months |
| Warranty 5 | 12 months |
| Electrical Connector | 2 Ring Gold Disk |
