Lithium Battery Vacuum Heat Sealing Machines for Pouch Cell Second Final Sealing

Call for Price

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare

Name: Battery Vacuum Sealing Machine
Sealing Width: 200mm
Applicaton: Pouch Cell Case Final Sealing
Warranty: 1 year
Product description: Lithium Batteries Equipment Secondary Vacuum Sealing Machine for Polymer Cell. This equipment is used for lithium pouch cell vacuumizing and final heat sealing after filling & electrolyte diffusion pr

Lithium Batteries Equipment Secondary Vacuum Sealing Machine for Polymer Cell after Electrolyte Filling

This equipment is used for lithium pouch cell vacuumizing and final heat sealing after filling & electrolyte diffusion process.

Features :
1. The sealing head is made of copper material so that the heat transfer effect is good to save
power consumption , improve work efficiency and more energy-saving than
other similar products.
2. Pressure of upper and lower sealing heads can be regulated by pressure regulating valve to meet different technological parameter demands.
3. The lower and upper sealing heads are driven by cylinder through two linear-guide bushes that makes them move up and down flexibly and ensures the parallelism demand after sealing.
4. It’s designed with puncture function.
5. The lid of chamber is driven by cylinder through linear-guide bushes that makes them flexibly and ensures the good sealing.
6. It can be used for different battery, easy adjustment.
7. Simple operation, nice appearance, small size, light weight

Video

Battery heat Sealing Machine TOB YF350 S

TOB-YF350-S compact vacuum sealing machine is a manual pouch sealing machine mainly used for Heat sealing aluminum-laminated case in glove box after ...

Pouch Cell Flat Lithium Ion Battery Final Vacuum Sealing Machine Operational Video

Description PC-FVS-110 is a compact vacuum sealer for pouch cell. This is used for the final seal the pouch cell. This is kept in the dry atmosphere.

Pouch cell vacuum sealing machine

MRX-YF200 vacuum sealing machine for pouch cell research .
