Advanced Instruments PSR-12-333 PPM Oxygen Sensor

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare

This sensor is specifically designed for Advanced Instruments, Inc., trace oxygen analyzer, explosion proof, intrinsically safe transmitters, and portable analyzers.
GPR-1600
GPR-1200
GPR-1100
GPR-18
GPR-1800 Series
GPR-1500 Series
This innovative sensor design carries over many of the features of the traditional galvanic oxygen sensor but poses much higher sensitivity, stability and high signal to noise ratio with 24 months operating life thus offering effective analyzer solution for measuring low levels PPM oxygen analysis.

$399.00 $268.00

100 in stock

Measuring Range 0-10 PPM Oxygen
Accuracy 1 +/-2% of Full Scale
Signal Output 2 295 – 625 uA
Linearity +/-2% of Full Scale
Response T90 7 sec
Temp Coefficient compensated
Operating Temp 0 to 45oC
Recommended Storage 3 0 to 25°C
Temperature Coefficient Compensated
Shelf Life 4 6 months
Humidity Non-condensing 0-99% RH
Expected Life 18-24 months
Warranty 5 12 months
Electrical Connector 2 Ring Gold Disk
