Edwards APG100-XLC Corrosive Resistant Active Pirani Vacuum Gauge,KF25 Flange

- 51%


Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare

100 in stock

The Edwards APG100-XLC Corrosive Resistant Active Pirani Vacuum Gauge contains a NW25, KF25 vacuum flange, is compact for easy installation, has a linear output, and a user replaceable tube sensor. The new Edwards gauges are compatible with all Edwards TIC, ADC, TAG instrument controllers and other active gauge controllers and displays. They are also CSA, C/US approved as well as fully RoHS compliant due to their lead-free construction. They measure pressure from 1000 down to 10-4 mBar. The signal cables and TIC vacuum gauge controllers are sold separately. The instruction manual for these Edwards APG100 series gauges is available in PDF format below. The APG100 is available in two versions: the ‘M’ version (contains standard Tungsten/Rhenium filaments) can measure pressure down to 10-3 mBar and is suitable for general applications; the ‘LC’ version (contains corrosive resistance Platinum/Iridium filaments) can measure pressure down to 10-4 mBar and is also suitable for use in corrosive applications.

The APG100 can be mounted in any orientation however the gauge tubes are individually factory calibrated in nitrogen whilst vertical. For correct pressure indication in your chosen gauge orientation, the gauge should be recalibrated at atmospheric pressure. Edwards recommends mounting the gauge tube vertical in order to minimize the build up of process particulates and condensable vapors within the gauge. he APG100 is calibrated for use in nitrogen, and will read correctly with dry air, oxygen and carbon monoxide. For any other gas type a conversion is required in order to obtain the correct pressure reading, common gases: nitrogen, argon, carbon dioxide, helium, krypton and neon.

Features Include:

  • Easy Access to signal cable with compact enclosure
  • Sensor bakeable to 150°C (300°F) and sensor is user replaceable
  • Adjustable set point for simple process control and interlocking
  • Remote calibration possible
  • Pressure range 10-4 mBar
  • Linear output – 1 Volt per decade for easy interface with vacuum control systems

Technical Data

Mass 85 g
Internal volume 5 cm3
Enclosure rating IP40
Measurement range (APG100-XM) Atmosphere to 10-3 mbar
Measurement range (APG100-XLC) Atmosphere to 10-4 mbar
Accuracy (APG100-XM) Typically +/- 15% at <100 mbar
Accuracy (APG100-XLC) Typically +/- 15% at <10 mbar
Maximum over-pressure 10 bar absolute
Operating temp range 5o to 60o C
Storage temp range -30o to 70 oC
Bake-out with no electronics 150 oC
Humidity 80% RH up to 31 oC decreasing linearly
to 50% RH at 40 oC and above
Maximum altitude 3000 m
Filament temperature 100 oC above ambient
Electrical supply voltage 15 to 30 V d.c. nominal
13.5 V d.c. minimum
32 V d.c maximum
Power consumption 1 W
Output signal 0 to 10 V d.c. nominal
Set-point – open collector transistor
  Rating 30 V d.c. 100 mA
  Range of set-point 1.8 to 9.2 V dc
  Fixed hysteresis 500 mV (1/2 decade)
  Level setting resolution 6 mV
