QUICK CLAMP KF-10 KF-16 WITH WING-NUT ASSEMBLY, NW-10 NW-16, ALUMINUM
100 in stock
KF Hardware (also referred to as NW) assemblies consist of two Flanges, a Center-Rings and an aluminum Clamp. Quick Clamps are assembled with wing nuts to insure ease of use over time without tools. A uniform application of pressure on the clamp insures a vacuum seal. The mating flange surfaces compress the O-Ring, which is held in place by a metal centering ring, to generate the vacuum seal.
Delivery from USA, it takes about 3-5 days to arrive at.
The Quick Clamp KF-10 and KF-16 with Wing-Nut Assembly is used to connect vacuum plumbing and process systems in combination with vacuum pumps or vacuum components.
The Cast Aluminum Clamps KF-10 and NW-16 Clamp is used in conjunction with a certering ring with a fitted O-ring for mating KF flanges..
- A: 2.48 in / 63 mm
- B: 1.67 in / 42.5 mm
- C: 0.63 in / 16 mm
The KF 16 and NW 16 Clamps are available in the following sizes: NW 16, NW 25, NW 40, NW 50
