20 in Cubic Vacuum Chamber, Preconfigured with CF Flanges and User Selectable Latching Door, Stainless Steel
100 in stock
Fabricated and assembled entirely in our manufacturing facility, these robust, inexpensive vacuum chambers are a highly efficient way for your R&D lab to get into high vacuum applications. With an internal dimension of at least 20 x 20 x 20 inches, all of these cubic chambers are made with corrosion resistant 304 stainless steel plate . These leak-tested chambers are internally TIG welded, and include an O-ring seal, sturdy hinged door, and easy open latch for quick access. Your choice of door includes an inexpensive aluminum door, a stainless steel door for chemical resistance, a clear acrylic door for direct viewing, and coming soon, a machined aluminum door for fixturing feedthroughs and miscellaneous internal components. All plates have a sanded finish and are electropolished on the internal side.
- Interior Chamber Size: Approximately 20X20X20 inches (approx. 51X51X51cm)
- Ports Include: 1 x CF 6 in, 2 x CF 3.375 in, 2 x CF 2.75 in, 2 x CF 1.33 in
- Chamber Material: 304 Stainless Steel
- Weight: 280 lbs (127 kg) w/o door
- Volume: 4.8 cu. ft. (137.3 liters)
- Hinged Front Door: Aluminum, Stainless Steel, or Acrylic
- Ultimate Pressure: 1×10-6 Torr (High Vacuum)
- Leak Tested: (Helium) to 1×10-8 atm cc/sec
- Operating Temperature Range (Viton Seal): 5° to 302°F (-15° to 150°C)
- Lead Time: One to Two Weeks (7-14 days)
- Call for additional porting options
- Call for expanded temperature range
