Significant Advantages of Electric Ball Valve

SaveSavedRemoved 0
Deal Score0
Deal Score0
  1. The valve stem is reliable in sealing. Because the valve stem is only used for imitating rotation and not lifting, the packing seal of the valve stem is not easy to be damaged, and the sealing ability increases with the increase of the pressure of the medium.
  2. Since materials such as polytetrafluoroethylene have good self-lubricity and small friction loss with the ball, the service life of the ball valve is long.
  3. The fluid resistance is small. The ball valve is the smallest fluid resistance of all valves. Even the reduced diameter ball valve, its fluid resistance is quite small.
  4. The thrust bearing reduces the friction moment of the valve stem, which can make the valve stem operate smoothly and flexibly for a long time.
  5. The bottom-mounted valve stem and the convex step of the valve stem head prevent the valve stem from spraying out. If the valve stem seal is damaged due to fire, the convex step and the valve body can also form metal contact to ensure the valve stem seal.
  6. Anti-static function: a spring is set between the ball, valve stem and valve body, which can lead out the static electricity generated during the switching process.
  7. The valve seat has good sealing performance. The sealing ring made of PTFE and other elastic materials is easy to seal, and the valve sealing capacity of the ball valve increases with the increase of the medium pressure.
  8. View more quality vacuum valves with low price and free shipping all over the world.
