Causes and Treatment of Valve Body Leakage of Blank Plate Valve

labiedal001 March 12, 2020 Vacuum fittings, Valve

SaveSavedRemoved 0

Deal Score0

19

Deal Score0

Causes of valve body leakage of vacuum flapper valve and its treatment

1. The valve body has sand holes or cracks;
2. Crack during repair welding of valve body

Handle:

1. Polish the suspected crack and etch it with 4% nitric acid solution, if there is crack, it can be shown;
2. Repair the cracks.

Reasons for damage of valve rod and its matching screw thread, broken stem head and bent stem:

1. Improper operation, excessive switch force, failure of limit device and failure of over torque protection. ;
2. The thread fit is too loose or too tight;
3. Too many operations and too long service life

Handle:

1. Improve the operation, do not use too much force; check the limit device, check the over torque protection device;
2. Select appropriate materials, and the assembly tolerance meets the requirements;
3. Replacement of spare parts
