Compact Vacuum Film Coating Machine with Dryer for Battery Electrode
100 in stock
Product description: BATTERY ELECTRODE VACUUM COATING MACHINE WITH DRYER. It’s a film hot coater which widely used in all kinds of high- temperature film coating research,for example ceramic films, crystal films, battery mate
Built in Vacuum Pump
Touch Screen Control
Coating Width: 150mm
- Touch-screen ,easy operation.
- Temperature controlled heating system is digital displayed, max working temperature is 200℃.
- Timer is digital displayed; the heating time can be set freely.
- Coating speed can be regulated at a range of 0~200mm/s.
- Vacuum aluminum plate used to place and take off the substrate quickly.
- Stroke can be regulated by touch screen at a range of 10~250mm.
- Coating thickness can be regulated, the accuracy is 0.01mm.
- Nice appearance, solid geometry design makes well- formed shape.
- Application :Battery lab;Battery research;Lithium ion battery lab;Material research;Trial-production and so on.
Lab Vacuum Film Coating Machine WWW.TMAXCN.COM
http://www.battery-equipments.com/lab-film-coating-machine_c2.html The coating machine with vacuum chuck, oilless vacuum pump, and micrometer ...
