16 in Cubic Vacuum Chamber, Preconfigured with CF Flanges and User Selectable Latching Door, Stainless Steel

- 25%

$8,810.00 $6,610.00

Add to wishlistAdded to wishlistRemoved from wishlist 0
Add to compare

100 in stock

Quantity Price
5 - 10 $6,279.50 ( 5 % Discount )
11 - 20 $5,949.00 ( 10 % Discount )

Fabricated and assembled entirely in our manufacturing facility, these robust, inexpensive vacuum chambers are a highly efficient way for your R&D lab to get into high vacuum applications. With an internal dimension of at least 16 x 16 x 16 inches, all of these cubic chambers are made with corrosion resistant 304 stainless steel plate . These leak-tested chambers are internally TIG welded, and include an O-ring seal, sturdy hinged door, and easy open latch for quick access. Your choice of door includes an inexpensive aluminum door, a stainless steel door for chemical resistance, a clear acrylic door for direct viewing, and coming soon, a machined aluminum door for fixturing feedthroughs and miscellaneous internal components. All plates have a sanded finish and are electropolished on the internal side.

Specifications

  • Interior Chamber Size: Approximately 16X16X16 inches (approx. 40.6X40.6X40.6cm)
  • Ports Include: 1x CF 6 in, 2x CF 3.375 in, 2x CF 2.75 in, 2x CF 1.33 in
  • Chamber Material: 304 Stainless Steel
  • Weight: Approximately 160lbs (73Kg) w/o door
  • Chamber Volume: Approximately 2.46 cu. ft. (69.6 liters)
  • Hinged Front Door: Aluminum, Stainless Steel, or Acrylic
  • Ultimate Pressure: 1×10-6 Torr (High Vacuum)
  • Leak Tested: (Helium) to 1×10-8 atm cc/sec
  • Operating Temperature Range (Viton Seal): 5° to 302°F (-15° to 150°C)
  • Lead Time: One to Two Weeks (7-14 days)
  • Call for additional porting options
  • Call for expanded temperature range
